3Kw 224m 4Hp Aico Borehole Pump – DW4000-3 Three Phase 4800L/H Deep Well Submersible Water Pump
KSh53,995.00KSh96,000.00 (-44%)
-
⚙️ Power: 3.0 kW / 4 HP (Three-Phase)
-
⬆️ Lift: 224 m Deep-Well Performance
-
???? Flow: 4800 L/h (≈ 5 m³/h)
-
⚡ Voltage: 380 – 415 V Three-Phase
-
???? Requires Starter Panel with Protection
-
????️ Durable Stainless + Thermoplastic Build
-
☀️ Solar / Grid Hybrid Compatible
-
???? Built with Macire Excellence for Extreme Depth and Reliability!
#MacirePower #BoreholePump #AicoJapan #DeepWellPump #WaterSupply #RenewableEnergy #WaterSolutions #GoGreen
You may also like
-
KSh4,499.00Inquire via WhatsApp
KSh8,760.00
???? 4.0 HP Aico Borehole Pump DW4000-3 – 224 Metres Deep Well Submersible Water Pump (Three-Phase) ????
???? Extreme Depth Power & Precision Performance – by Macire
The Macire Aico DW4000-3 is a 4.0 HP Three-Phase Deep-Well Submersible Pump designed for ultra-deep water lifting up to 224 metres.
With a steady flow rate of 4800 L/h, this powerhouse pump guarantees uninterrupted, high-pressure water delivery for commercial estates, agricultural projects, institutions, and industrial facilities.
Crafted with stainless-steel precision, heavy-duty copper windings, and reinforced thermoplastic impellers — this model is the top-tier performer in the Macire water solutions range.
⚙️ Full Technical Specifications
| Specification | Details |
|---|---|
| Model | Aico DW4000-3 |
| Power | 3.0 kW / 4.0 HP |
| Flow Rate | 4800 L/h (≈ 5 m³/h) |
| Max Head (Lift) | 224 m |
| Voltage | 380 – 415 V AC (Three-Phase) |
| Frequency | 50 Hz |
| Material | Stainless-Steel Casing + High-Strength Thermoplastic Impellers |
| Motor Type | Copper-Wound, F-Class Insulated |
| Protection | Thermal & Overload Protected (starter panel required) |
| Outlet Size | 1.25 inch |
| Water Type | Clean Water Only |
| Installation | Vertical – Fully Submersible (Deep Well) |
???? Application Areas
-
???? Estates & Apartment Complexes – steady, multi-household pressure
-
???? Large Farms & Irrigation Schemes – continuous water supply over long distances
-
???? Schools, Hospitals & Institutions – reliable 24-hour delivery
-
???? Hotels & Resorts – constant water pressure across floors
-
???? Industrial Facilities – tank filling, wash bays & manufacturing process water
???? Professional Installation Tips
-
Verify 3-phase supply (380 – 415 V) before installation.
-
Use a proper DOL or Star-Delta starter panel with overload and phase-failure protection.
-
Lower pump vertically using steel or nylon cable – avoid wall contact.
-
Check rotation direction before final submersion.
-
Use waterproof armored cable and tight gland seals.
-
Fit a non-return valve at the outlet for pressure retention.
????️ Care & Maintenance
-
???? Clean intake filter every 3–6 months.
-
⚡ Inspect starter panel contacts and relays quarterly.
-
???? Keep fully submerged to avoid dry run damage.
-
???? Monitor insulation resistance and tighten cable terminals annually.
-
???? Service once per year or after prolonged heavy usage.
✅ Do’s & Don’ts
✔️ Do’s
-
Ensure balanced 3-phase connections.
-
Install correct breakers and earth bonding.
-
Operate within rated depth and voltage.
❌ Don’ts
-
Don’t run pump dry or partially submerged.
-
Don’t use in sandy or muddy wells.
-
Don’t bypass starter panel protection.
☀️ Solar Integration Scenarios
| Setup | Recommended Solar Power | Controller Type | Battery Bank | Ideal Use |
|---|---|---|---|---|
| Large Farm | 5 kW Solar Array | 3-Phase Hybrid Inverter | 4 × 250 Ah | Irrigation + tank filling |
| Estate Water System | 7 kW Solar | 3-Phase Hybrid Inverter | 6 × 250 Ah | Continuous domestic supply |
| Industrial Use | 9 kW Solar | 3-Phase Hybrid MPPT | 8 × 300 Ah | 24-hour process operation |
???? Water Tank Capacity Guide
| Users / Application | Suggested Tank Size | Estimated Pump Cycles |
|---|---|---|
| 10 – 15 users | 2000 – 3000 L | 2–3 cycles/day |
| 20 – 30 users | 5000 – 8000 L | 1–2 cycles/day |
| Farm / Industrial | 10 000 L + | Continuous supply |
❓ Mini FAQ
Q1: Is this model suitable for very deep boreholes?
A: Yes – it can lift water from depths up to 224 metres.
Q2: Does it require a control panel?
A: Yes – a three-phase starter panel with overload and phase-failure protection is mandatory.
Q3: Can it run on solar power?
A: Yes – when paired with a 3-phase hybrid solar inverter.
Q4: What’s the flow rate?
A: Around 4800 L/h under standard operating conditions.
Q5: Is it safe for drinking water?
A: Yes – constructed with non-toxic materials suitable for potable applications.
???? Why Choose Macire Borehole Pumps?
-
???? Extreme depth performance with industrial-grade efficiency
-
⚙️ Three-phase design for smooth operation & energy savings
-
???? Hybrid-ready – runs on solar or grid
-
???? Stainless-steel body + thermoplastic impellers for durability
-
???? Trusted Macire reliability and after-sales support
#BoreholePump #ThreePhasePump #DeepWellPump #SubmersiblePump #WaterSupplySolutions #SolarWaterSystem #Macire #AicoPump #WaterPumps #EcoFriendly #EnergySavings #ReliableWater
