The Dayliff DGW welding generator is a dependable, quality product specially designed for welding and generating simultaneously or separately. Particular features include:

Options of reliable and economical air-cooled 4 stroke OHV petrol engine (DGW 200P)or high efficiency diesel engine (DGW200D) equipped with large size exhaust and air cleaner for low noise operations.
High efficiency square core alternator providing increased power output and enabling operation of sensitive electronic equipment.
AC auxiliary current and DC welding current can be used simultaneously.
DC output for battery charging.
Strong tubular frame for protection and ease of handling.
Integrated control panel with voltmeter and welding current adjuster for operational convenience.
Fuseless type over current protection for AC.
Engine oil level sensor for protection in case of low oil level.
High capacity fuel tank for extended operation.
Supplied complete with electrode holder and 4m cable, welding clamp and 4m cable, output plugs and separate castor wheels for movable applications.

The DGW welding generator is of compact design and its advanced features make it suitable for all small scale welding and generation applications.

Generator Information
Output – Rated(kVA)	5
Output – Max(kVA)	5.5
Engine Model	LT420V
Engine Rated Power (HP)	10.5
Engine Capacity(cc)	420
Fuel Tank Capacity(L)	25
Operating Period	7
Weight(kg)	107
Starter	Electric
L (mm)	685
W (mm)	520
H (mm)	625
Electrical Data
Alternator	Brushless, self exciting, 2 pole
Power Output	50Hz, 240V, single phase
Voltage Regulator	AVR
Power Factor	1
Direct Current	12V/8.3A
Speed	3000rpm
Derating	Given outputs are sea level ratings. Sets should be derated at 1% for every 100m higher than 100m above ea levels, and 2% for every 5C temperature above 20C
Welding Data
No Load Voltage(V)	65
Operating Voltage(V)	28-35
Operating Current(A)	50-140
Max Arching Current(A)	200
Welding Rod Current 2.5mmØ	50-100
Welding Rod Current 3.2mmØ	100-160
Welding Rod Current 4mmØ	160-200
