56m 750w Solar Borehole Pump Kit 6000L/H – Trunsun 4DPC6-56-48-750 DC 48v

Introducing the Macire 56m 750W Solar Borehole Pump Kit 6000L/H – Trunsun 4DPC6-56-48-750 DC 48V

Elevate your water management system with the Macire 56m 750W Solar Borehole Pump Kit, designed to deliver efficient and sustainable water solutions for various applications.

Key Features:

• High Performance: Pumps up to 6,000 liters per hour, ensuring a reliable water supply for diverse needs.
• Deep Well Capability: Effectively extracts water from depths up to 56 meters, suitable for deep wells and boreholes.
• Solar-Powered Efficiency: Operates on a 48V 750W DC system, harnessing solar energy to reduce electricity costs and promote environmental sustainability.
• Durable Construction: Built with high-quality stainless steel components, offering resistance to corrosion and extending the pump’s lifespan.
• Advanced Protection Features: Equipped with water shortage protection, soft start technology, and safeguards against over-voltage, low voltage, over-current, and high temperatures, ensuring safe and efficient operation.

Applications:

• Residential Use:
  • Provide a consistent and reliable water source for household needs.
  • Efficiently irrigate gardens and landscapes.
  • Sustainably fill swimming pools.
  • Facilitate car washing with ease.
• Agricultural Use:
  • Implement effective drip irrigation systems.
  • Ensure dependable water access for livestock.
  • Enhance crop yields through optimized water management.
• Community Projects:
  • Deliver clean water solutions to areas in need.
  • Support sustainable agricultural initiatives.
  • Empower communities with access to essential water resources.

Maintenance Tips:

• Regular Inspection: Periodically check the pump and solar panels for any signs of wear or damage.
• Clean Solar Panels: Keep the solar panels clean from dust and debris to maintain optimal efficiency.
• Monitor Water Quality: Ensure the water source is free from large particles that could clog the pump.
• Professional Servicing: Schedule annual maintenance with a qualified technician to prolong the pump’s lifespan.

DIY Installation Guide:

1. Site Assessment:
   • Identify a suitable location with maximum sunlight exposure for the solar panels.
   • Ensure the water source is accessible and the well depth does not exceed 56 meters.
2. Mounting Solar Panels:
   • Install the 4x340W solar panels on a sturdy frame, angled to capture optimal sunlight.
   • Connect the panels in series or parallel as per the voltage requirements.
3. Pump Installation:
   • Attach the submersible pump to the safety cable and lower it into the well to the desired depth.
   • Connect the 60-meter submersible cable to the pump and route it to the controller.
4. Electrical Connections:
   • Connect the solar panels to the MPPT controller, ensuring correct polarity.
   • Link the controller to the pump using the submersible cable.
5. System Testing:
   • Once all connections are secure, test the system by exposing the panels to sunlight.
   • Verify the pump operates smoothly and water is being delivered as expected.

Frequently Asked Questions (FAQs):

• Q: What is the warranty period for the Macire 56m 750W Solar Borehole Pump Kit?
  • A: The pump comes with a 2-year warranty covering manufacturing defects.
• Q: Can the system operate on cloudy days?
  • A: Yes, the system can function under diffused sunlight, though performance may be reduced.
• Q: Is professional installation required?
  • A: While DIY installation is possible, professional installation is recommended to ensure optimal performance and longevity.

Package Includes:

• 1 x Trunsun 4DPC6-56-48-750 DC 48V 750W Submersible Pump
• 4 x 340W High-Efficiency Solar Panels
• 1 x MPPT Controller
• 1 x 60m Submersible Cable

Note: Additional items such as safety cable, poly pipe, and wire power cable are required for installation and operation.

Model	Voltage	Power	Max. Flow	Max.Head	Outlet
4DPC6-42-48-600	48V	300W	6m3/h	42m	1.25″
4DPC6-42-72-600	72V	400W	6m3/h	42m	1.25″
4DPC6-56-48-750	48V	600W	6m3/h	56m	1.25″
4DPC6-56-72-750	72V	600W	6m3/h	56m	1.25″
4DPC6-84-72-1100	72V	750W	6m3/h	84m	1.25″
4DPC6-84-110-1100	110V	750W	6m3/h	84m	1.25″
4DPC6-112-110-1300	110V	1100W	6m3/h	112m	1.25″
4DPC6-135-110-1500	110V	1100W	6m3/h	135m	1.25″
4DPC9-45-110-750	110V	1300W	9m3/h	45m	2″
4DPC9-58-110-1300	110V	1500W	9m3/h	58m	2″
4DPC9-71-110-1500	110V	1500W	9m3/h	71m	2″
4DPC11.5-30-72-750	72V	750W	11.5m3/h	30m	2″
4DPC11.5-49-110-1100	110V	1100W	11.5m3/h	49m	2″
4DPC11.5-55-110-1300	110V	1300W	11.5m3/h	55m	2″
4DPC13-60-110-1500	110V	1500W	13m3/h	60m	2″
