Features :

◆ Lead acid / Lithium battery compatible.

◆ Toroidal transformer with low idle consumption.

◆ Battery DOD adjustable to meet different demand.

◆ Inbuilt MPPT solar controller, maximize the solar energy.

◆ Working mode AC prior/ECO mode/Battery prior selectable.

◆ Support utility supply input with AC charge current selectable.

◆ Fault codes on the display to guide diagnosis & troubleshooting.

◆ Continuous stable pure sine wave output with inbuilt AVR stabilizer.

◆ 4 LED indicator AC/BAT/INV/FAULT, easier to know working status.

◆ LCD display with multi-function, real-time display for dynamic values.

◆ Inbuilt automatic AC charger and AC mains switcher, stwitch time ≤ 4ms.

◆ Standard RS232 communication port, support APP monitor with WIFI module.

Parameters Table:

Specification
Model		ZD-T10240M	ZD-T15240M	ZD-T20260M	ZD-T30260M	ZD-T40280M	ZD-T50280M	ZD-T60280M
Capacity	Rated power	1500VA/1000W	2000VA/1500W	3000VA/2000W	4000VA/3000W	6000VA/4000W	7000VA/5000W	8000VA/6000W
	Peak power(20 millisecond)	4500VA/3000W	4000VA/3500W	9000VA/6000W	12KVA/9000W	18KVA/12KW	21KVA/15KW	24KVA/18KW
Input	Battery type	Lead acid / Lithium
	Stardard battery voltage	12/24VDC		24/48VDC		48VDC
	AC input voltage range	145-275VAC		170-275VAC
	AC input frequency range	55-65Hz
Output	Conversion efficiency	≥90%(Battery mode); >99%(AC mode)
	Output voltage	220VAC±2%(Battery mode); 220VAC±10%(AC mode)
	Output frequency	60Hz±1%(Battery mode); Tracking Automatically(AC mode)
	Output waveform	Pure Sine Wave
	THD	≤3%
AC charger	AC charging current	0-15A selectable		0-30A selectable
	AC charging method	Three-stage(constant current, constant voltage, floating charge)
MPPT solar charger	Charging mode	MPPT inteligent charging
	MPPT efficiency	＞98%
	Max PV input voltage(at 25℃)	120V		150V
	Recommended voltage range	15-100V/12V; 30-100V/24V		30-120V/24V; 60-120V/48VDC
	Charge/discharge current	40A		60A		80A
	Max PV input power	560W/12V; 1120W/24V		1680W/24V; 3360W/48V		4480W
Other	Transfer time	≤4ms
	Protection	with over-voltage, low-voltage, overload, short circuit, high tempreature protections
	Display	LCD + LED
	Cooling way	Cooling fan in intelligent control
	Communication	RS232/RS485(Optional)
Working mode	d1	AC priority mode
	d2	ECO priority mode
	d3	Solar priority mode
Work environment	Operating temperature	-10℃-40℃
	Storage temperature	-15℃-60℃
	Elevation	2000m(More than derating)
	Humidity	0%-95%, No condensation
Physical	Dimention, L x W x H(mm)	345253120		472328143		517363153
	Net weight(kg)	11.5	13.5	20	22	24	28	30
Packing	Dimention, L x W x H(mm)	565395225		542410242		582445253
	Gross weight(kg)	13	15	21.5	23.5	26	30	32
	Quantity/CTN	1pcs per carton
