30Kw 48v Deye Hybrid Solar Inverter – 3 Phase Dual MPPT – High Voltage

30kW 48V Deye Hybrid Solar Inverter – 3 Phase Dual MPPT – High Voltage ⚡????

Experience the ultimate in solar energy management with the 30kW 48V Deye Hybrid Solar Inverter, a high-performance, versatile, and reliable inverter for both on-grid and off-grid applications. Engineered for excellence, this inverter combines advanced technology with unmatched efficiency, ensuring optimal energy utilization for residential, commercial, and industrial setups. Backed by Macire’s commitment to quality and performance, this inverter is your go-to solution for sustainable energy management. ????

Key Features & Benefits ????

• ???? 100% Unbalanced Output: Supports each phase, with maximum output up to 50% of the rated power.
• ???? Dual MPPT Technology: Optimize energy harvest with 3/4 independent MPPT trackers for maximum efficiency.
• ???? AC Coupling: Ideal for retrofitting existing solar systems.
• ⚡ Parallel Operation: Connect up to 10 units for both on-grid and off-grid setups.
• ???? High Voltage Battery Compatibility: Enhanced efficiency with a voltage range of 160V-800V.
• ⏰ Flexible Battery Management: Six customizable charging/discharging time periods.
• ???? Generator Integration: Seamlessly store energy from a diesel generator for uninterrupted power.
• ???? Low Noise Operations: Operates at ≤65 dB(A), perfect for noise-sensitive environments.

Applications ????????

This robust inverter is suitable for diverse applications:

• ???? Residential: Power your home efficiently, ensuring reliability even in remote areas.
• ???? Commercial: Scale your business’s energy needs with parallel configurations and high efficiency.
• ???? Industrial: Supports heavy-duty energy requirements with peak power capabilities.

Technical Specifications ????

• Battery Input:
  • Type: Lithium-ion
  • Voltage Range: 160V-800V
  • Max Charging/Discharging Current: 50A + 50A
• PV Input:
  • Max DC Input Power: 39,000W – 65,000W (model dependent)
  • MPPT Efficiency: >99%
• AC Output:
  • Rated Power: 30,000W
  • Efficiency: Up to 97.6%
• Protection: Comprehensive safeguards including DC polarity reverse connection, AC overcurrent, short circuit, thermal, and surge protection.
• Environmental:
  • Operating Temperature: -40°C to +60°C
  • IP Rating: IP65 for outdoor installations

Maintenance Tips for Longevity ????

To ensure the Macire 30kW inverter delivers peak performance:

1. ???? Clean Regularly: Dust and debris can impact cooling efficiency. Use a dry cloth to clean vents and surfaces monthly.
2. ⚙ Inspect Connections: Check cables and terminals for wear and tear every 6 months.
3. ???? Optimal Placement: Install in a shaded, ventilated area to avoid overheating.
4. ???? Battery Care: Follow recommended battery maintenance for lithium-ion systems.
5. ???? Update Firmware: Keep the system updated for enhanced performance and new features.

DIY Guide: Installation & Setup ????

• Step 1: Mount the inverter securely on a flat surface, ensuring proper ventilation.
• Step 2: Connect the PV input cables to the designated terminals.
• Step 3: Attach the battery input cables and ensure polarity alignment.
• Step 4: Set up communication interfaces (WiFi, RS485, CAN) for monitoring.
• Step 5: Power on the system and configure via the LCD screen or remote app.

Do’s ✅:

• Follow the user manual during setup.
• Use appropriate tools and connectors.
• Ensure proper grounding to avoid electrical hazards.

Don’ts ❌:

• Don’t expose the inverter to direct sunlight or rain.
• Avoid overloading the system beyond its rated capacity.
• Don’t operate without checking all safety measures.

FAQs ❓

1. Can the inverter handle unbalanced loads?
   • Yes, it supports unbalanced output with up to 50% rated power per phase.
2. Is this inverter suitable for off-grid setups?
   • Absolutely! It supports off-grid and hybrid operations with parallel configurations.
3. What is the warranty period?
   • 5 to 10 years, depending on the installation site and terms.
4. Can I monitor the inverter remotely?
   • Yes, it features WiFi and RS485 communication interfaces for real-time monitoring.
