12kW Solis S6-EH 3-Phase Low Voltage Hybrid Inverter – 48V Battery, Triple MPPT, Commercial Energy Control

???? 12 kW Solis S6‑EH 3‑Phase Low Voltage Hybrid Inverter – Efficient High‑Performance Power Management

Deliver uninterrupted solar power and energy storage with the 12 kW Solis S6‑EH 3‑Phase Low Voltage Hybrid Inverter. Engineered for commercial and large residential solar installations, this intelligent hybrid inverter from Solis is optimized for energy independence and supported by Macire’s trusted after-sales service.

⚡ 12 kW 3‑phase hybrid inverter designed for solar plus battery systems
???? Supports 120–800 V lithium battery with 50 A charge/discharge capacity
???? Dual MPPT design with 4 input strings (20 A each) for maximum solar capture
???? UPS backup switch in under 10 ms—ideal for power outages
???? Features Wi‑Fi, Ethernet, Bluetooth/App monitoring, CAN/RS485 interfaces
????️ Robust IP66 housing and advanced safety protections
✅ Available through Macire – your solar energy partner in Kenya

⭐ Key Features & Benefits

• High efficiency up to 97.7 % (Euro), with near‑98.5 % charging efficiency

• Supports solar + battery hybrid mode, automatic UPS switching in <10 ms, backup port separation for critical vs non-critical loads

• Compatible with heat pump (SG) systems, ideal for integrated energy solutions

• Peak shaving modes, intelligent self‑use load management, programmable schedules for grid export or bill optimization

• Handles unbalanced or half-wave loads without interruption on both grid and backup sides

• Generator support: auto-detects and integrates generator input for extended backup duration

• Modern control & monitoring via LCD display, Bluetooth, App interface; optional Wi‑Fi, LAN, cellular remote access

???? Technical Specifications

???? Ideal Applications

• Commercial rooftop solar systems

• Residential solar + battery storage installations

• Backup power for critical loads (UPS behavior)

• Off-grid or micro-grid systems with generator integration

• Smart load management and solar self-consumption setups

???? Setup & Operation Guide

1. Mount inverter indoors or in sheltered outdoor location (ensure IP66 rating).

2. Connect solar panels with MC4 connectors to MPPT inputs.

3. Wire lithium battery bank via OT terminals (120–800 V range).

4. Connect grid/generator and critical backup circuits accordingly.

5. Configure operating mode (self-use, peak-shaving, backup priority).

6. Monitor via LCD panel, SolisCloud App or Ethernet access.

???? Maintenance Tips

• Keep the unit free of dust and provide ventilation for the cooling fan.

• Periodically update firmware via SolisCloud or installer interface.

• Test backup switching and generator interface annually for reliability.

• Inspect DC isolator, wiring, and connectors for wear and tightness.

• Ensure inverter is not exposed to extreme heat beyond –25 °C to +60 °C range

❓ Frequently Asked Questions (FAQs)

Q1: Can I parallel multiple units for higher capacity?
Yes—Solis S6-EH supports parallel operation of up to 6 inverters for up to 72 kW of backup power.

Q2: Does it support off-grid or generator modes?
Yes—features generator detection, off-grid switching, and critical / non-critical backup ports.
Compatible with Li-ion and LFP batteries from 120 V up to 800 V.

Q4: What about exporting power back to the grid?
Peak shaving and export control modes supported; zero-export is under rollout and may be available by 2025.

Q5: Is Solis reliable long-term?
Solis units offer high efficiency and many smart features, though forum feedback suggests after-sales support and setup quality are key.

????️ Order via Macire Today

Get your 12 kW Solis S6‑EH 3‑Phase Low Voltage Hybrid Inverter from Macire, backed with expert installation, local warranty, and system support:

???? Call / WhatsApp: +254 718 762 530
???? Showroom: Barkat Biashara Mall, Kumasi Road – Opp. Simba Coach, Nairobi
???? Order Online: www.macire.co.ke
